TDS Mini Controller (0.0 to 199.9 ppm) – BL983315-12VDC
The BL983315 is a compact, panel mounted, process controller for measuring total dissolved solids (TDS) of a process stream that is within the 0.0 to 199.9 ppm (mg/L) range. The device features a large LCD with protective cover. Users may choose from automatic or manual dosing modes. When in automatic mode the dry contact relay is activated when a reading is above the set point. The relay can be used to supply power to a dosing pump or a solenoid connected to a valve. The BL983315 can also be used to monitor the quality of water produced from ion exchange, reverse osmosis (RO) or distillation.*The BL983315 uses a 0.5 conversion factor in which 1.0 ?S/cm = 0.5 ppm.?
Multicolor LED Indicator
LED changes color based on status.
Fire Retardant Casing
For additional safety the controllers outer case is made of fire resistant plastic.Splash Resistant CoverA clear plastic cover protects the face panel from dirt and liquids.
Productos Complementarios
Estándares CAL Check ™ de Flúor de Rango Bajo – HI97729-11
Consultar Disponibilidad
Fotómetro para Azúcares Reductores en el Vino – HI83746
Stock Disponible
$347.200+ IVA
DISPONIBLE
Agotado
SKU: BL 983315-0
Adjustable Dry Contact Dosing Relay
The BL983315 features a dosing relay that is activated when the reading is above a user programmable set point.
Programmable Overdose Protection
For enhanced safety the mini controller can be programmed to deactivate the dosing relay if the set point is not reached within a specified time interval. The overdosing timer is programmable from 5 to 30 minutes or disabled.
Relay Control Override
With the flick of a switch the mini controller’s relay can be disabled (Off), placed in control (Auto), or be activated for manual operation (On) which is useful for priming a dosing pump.
Multicolor LED Indicator
Multicolor LED indicator allows an operator to quickly check the status of the controller.
- Green = Meter in measurement mode and reading is below the set point.
- Orange/Yellow = Reading is above the set point and the relay is activated.
- Blinking Red = Indicates an alarm condition such as when the maximum dosing time has been exceeded.
Fuse Protected Dosing Contacts
The relay dosing contact is rated for up to a 2A load and is fuse protected.
Labeled Termination Connections
Quick-connect terminal blocks are clearly labeled for easy connection to power, conductivity probe and relay that can be used to operate a dosing pump, valve, audible alarm, or light.
1/2″ NPT Male Threaded Amperometric Probe for Mounting In-line*
The BL983315 mini controller uses the HI7634 conductivity probe that is available with different cable lengths.
*HI7634 is not included and must be ordered separately
| Intervalo | 0.0 a 199.9 ppm (mg/L) |
| Resolución | 0.1 ppm (mg/L) |
| Exactitud (@ 25°C / 77°F) | ± 2% escala completa |
| Factor de conversión de TDS | 0.5 |
| Calibración | Manual, con perilla CAL |
| Relé dosificador | Máximo 2A ?(protección con fusible), 250 VCA, 30 VCD |
| Selección de dosificación | Relé activado (contacto cerrado) cuando la medición es mayor que el punto de ajuste |
| Punto de ajuste | Ajustable de 0 a 199.9 ppm (mg/L) |
| Protección contra sobre dosificación | Regulable, típicamente de 5 a aproximadamente 30 minutos |
| Compensación de temperatura | Automático de 5 a 50°C (41 a 122°F) con beta = 2%/ºC |
| Fuente de alimentación | Modelos "-0": Adaptador de 12 VCD (incluido) Modelos "-1": 115/230 VCA; 50 / 60Hz |
| Dimensiones | 83 x 53 x 99 mm (3.3 x 2.1 x 3.9 '') |
| Peso | Modelos "-0": 200 g (7.1 onzas) Modelos "-1": 300 g (10.6 onzas) |
| Información para ordenar | El BL983315-1 (115/230 VCA) y el BL983315-0 (12 VCD) se suministran con soportes de montaje, cubierta transparente y manual de instrucciones. |
